Eliminator Series - Chemical Bench Top Fume Hoods
Most of our Eliminator Series fume hoods include these standard features:
- Best design to meet ADA requirements for K-12 and other markets
- Full frame construction
- Flush-mount airfoil
- Full-length finger lift
- Up to 10 electrical AND 10 plumbing fixtures per hood
- Fits through 34” door frames without disassembly
- Shaft drive counterbalance system
100 Airfoil Fume Hood
Designed with a 45-degree angle around the fascia and a flush-mount airfoil for minimized turbulence and increased performance.
Additional standard features:
- U.L. listed poly resin liner
- ASTM E84 modified PTFE liner available for highly corrosive applications
- 10″ round stainless steel duct collar
- Depths of 33, 39 and 45 available as standard.
- Widths of 3,4,5,6,7,8,10,12 wide available
- CV or VAV styles available
200 Double Sided Enclosure
Ideal for both high school classrooms and applications where front and back access is required. Includes a 45-degree angle around the fascia and a flush-mount radiuses airfoil.
Additional standard features:
- Sash interlock
- U.L. listed poly resin liner
- Knock-down capability
300 Thin Wall Fume Hood
Designed for nuisance vapors or heat.
Additional standard features:
- VAV or CV styles available
- Knock-down capability
- Available in many widths and depths
400 Floor Mount Fume Hood
Has a 72″ high opening. Available in many heights, depths and widths for customized use.
Additional standard features:
- U.L. listed poly resin liner
- Knock-down capability
- Shaft-drive counter-balance for vertical rising sashes
- Horizontal sliding sashes or vertical rising available or combination
- Double-sided available
- Distillation or “California Style” hoods available
500 ADA Specified Fume Hood
An airfoil type fume hood designed to meet ADA dimensional guidelines. Includes a containment trough and a pivoting airfoil for easy trough cleanup.
Additional standard features:
- Shaft drive counter balance system
- VAV or CV styles available
- Knock-down capability
- Painted steel secondary containment trough assembly
- Sash stop
- 1/4 turn ball valves
- 10 utilities can be mounted on hood and meet ADA requirements
600 Radio Isotope Fume Hood
Specifically designed to handle the use of radioactive and corrosive chemicals. Includes a one-piece stainless steel liner and countertop with radius construction.
Additional standard features:
- Shaft drive counter balance system
- 304 stainless steel one-piece integral work surface and liner
- 304 Stainless steel sash
- 304 Stainless steel airfoil
- VAV or CV styles available
700 Perchloric Acid Fume Hood
Includes a built-in trough to capture runoff from wash down procedures where perchloric acid is in use. Features 316 stainless steel interior, sash and airfoil.
Additional standard features:
- 316 stainless steel on-piece integral work surface and liner with welded in trough.
- Manual wash down system
- Stainless steel sash
- Stainless steel airfoil
- Stainless trough sink
800 Flat Front Fume Hood
An economical solution for K-12 education applications that need to rid of nuisance vapors.
Additional standard features:
- U.L. listed poly resin liner
- Knock-down capability
- 10″ round stainless steel duct
900 Demonstration Fume Hood
Features a slimmed down design that allows for more workspace, and three windows for optimum viewing. This hood is deal for educational and demonstration viewing when on an island or peninsula.
Additional standard features:
- U.L. listed poly resin liner
- Knock-down capability
- 10″ round stainless steel duct
- Sash Interlock
Spray Booth
The AMS Paint/Spray hood is ideal for smaller fume extraction projects. Its simple design includes a vapor-proof light as well as two filters set in an easy to change flange bracket system. Can be ordered with or without a blower and explosion proof options are available as well.
Additional standard features:
- 18GA Steel construction
- Corrosion resistant, epoxy powder coat finish
- Optional blower provides 100 LFM and ¾” static pressure
- Explosion proof options available
- Two Filters included
- Vapor-Proof Light
